Percentage Oxygen Sensor, Recommended Storage Temp 0 DegreeC to 20 DegreeC, Weight 16 g
Active
Premium
Key Highlights
₹ 11820.00
MOQ
1
Available Variants
Technical Specifications
| Parameter | Value |
|---|---|
| Brand | Teledyne / Southland Sensing |
| Weight | <16 g |
| Linearity | Can be considered linear in many cases. |
| Technology | Electrochemical |
| Output Signal* | 0.10 +- 0.02 mA in Air |
| Casing Material | ABS |
| Maximum Overload | 30% vol. O2 |
| Measurement Range | 1-25% vol. O2 |
| Thermal Transient | <23.5% vol. O2 |
| Model/ Part Number | AAY80-390 (40XV) |
| Pressure Transient | <200% signal change |
| Response Time (T90) | <15 Seconds |
| Pressure Coefficient | <0.02% signal/mbar |
| Zero Current (Offset) | <0.6% vol. O2 |
| Minimum Order Quantity | 1 |
| Long Term Output Drift* | <2% signal/month Typically <5% over operating life |
| Orientation Sensitivity | <0.2% vol. O2 equivalent |
| Relative Humidity Range | (at 0 DegreeC to 20 DegreeC) |
| Operating Pressure Range | Atmospheric +- 20% |
| Recommended Storage Temp | 0 DegreeC to 20 DegreeC |
| Recommended Load Resistor | 100 Ohm |
| Operating Temperature Range | -20 DegreeC to +50 DegreeC (up to 3 months continuous across RH range) |
Product Description
Leading Manufacturer and Supplier of Percentage Oxygen Sensors in Greater Noida
An oxygen 02 gas sensor is commonly used to measure oxygen concentrations in indoor air as well as capable of temperature compensated designed for application in different environments. These environments can range from psa nitrogen units, Cryogenics, Medical, Scientific, Welding, Modified and safety, Atmosphere packaging, To name a few. Oxygen sensors also have a wide measurement range, Allowing it designated for application to study human and cell respiration. What is a normal oxygen level for a gas detector? normal oxygen levels range between 19. 5% and 23% normal 20. 8% . Most oxygen gas sensors measure between an assortment of 0, 25%. How does an oxygen gas sensor work? oxygen gas sensors operate based on electrochemical ec technologies. This means they measure a chemical reaction within the sensor resulting in creates an electrical output, Proportional to the oxygen level.
