Material SS, Automation Grade Automatic Six Head Liquid Soap Filling Machine, Phase Three, Brand PCM

Brand: PCM

Active

Premium

Key Highlights

PCM Automatic 1

₹ 336600.00

MOQ

Quantity:

Available Variants

Material:

Power Consumption:

Voltage (V):

Minimum Order Quantity:

Brand:

Technical Specifications

Parameter	Value
Brand	PCM
Phase	Three
Material	SS
Voltage (V)	240
Automation Grade	Automatic
Power Consumption	2 kW
Minimum Order Quantity	1

Product Description

Comprehensive Guide to Using the Six Head Liquid Soap Filling Machine

The machine works on volumetric principal and is intended for fill varieties of liquid into a range of diverse categories of containers with precise accuracy on a continuous conveyor line. The unit shall have provision to fit stainless steel syringes. A specially designed synchronized mechanical movement with a conveyor system 6 ft. Long and a bottle indexing mechanism ensures smooth running belonging to the device a bottle not included fill mechanism prevents spillage of liquid when continuous flow of bottles is not available. Output std. Syrup type liquid 1000 ml 40 to 50 bottles/min shape of container, Volume of fill, Depending upon nature liquid & no. Of head. Container specifications body diameter A range of 25 through 100 mm flat bottles will not run on turn table you need to have a vibratory feeder or you need to load the bottles by hand on conveyor neck diameter 20 mm i. D. Minimum height up to 280 mm accuracy of fill, 1 %. Height of conveyor from ground level is 800 to 880 mm adjustable. Motor for main drive 1. 0 h. P. /1440 rpm, Tefc, 230/440 v, 6 lead suitable for vfd depending upon no. Of heads & volume of fill. Motor for conveyor 0. 25 h. P. /1440 rpm, Tefc, 230/440 v, 6 lead suitable for vfd.
