Material PVC Mounted Level Indicator, Type Simple, Voltage 250
Active
Premium
Key Highlights
₹ 16929.00
MOQ
1
Available Variants
Technical Specifications
| Parameter | Value |
|---|---|
| Type | Simple |
| Brand | NRG GLOBAL |
| Voltage | 250 |
| Material | PVC |
| Country of Origin | Made in India |
| Minimum Order Quantity | 5000 |
Product Description
Efficient Stock Management for PVC Mounted Level Indicators in Vadodara
Nrg global top mounted magnetic gauge is mounted on leading edge of the tank by a suitable process connection preferably 100 mm nb flange. A float designed for the liquid to be gauged is steered through a stilling well that rest on the process flange. The float is linked to a stem that has a magnet at the upper end moving in a chamber. The float combined with the stem and magnet moves up and down with the changing in liquid levels in the vessel. On the dry next to the chamber is the magnetic follower display assembly comprising of a red & black pp magnetic capsule contained within a glass tube filled with water. As the float tracks the fluid height the magnet inside the float magnetically couples the red & black pp capsule and the capsule will remain magnetically coupled as well as the degree can be read off directly technical features uncomplicated yet strong design. Pressure and gas proof separation of chamber and display. Measuring and indication of the degree of aggressive, Combustible, Toxic, Hot agitated and contaminated liquids. Magnetic follower display without external power. Available for applications in all areas of industry through use of highly corrosion resistant materials designs for a pressure range from full vacuum to 30 bar designs for a spectrum of temperatures from 100c to 250o c food industry design. Interface measurement. Options nrg global magnetic switches serve the purpose of monitor certain limits of the level. The obtained binary signal can be forwarded to trigger alarms or other controls. Nrg global level sensors are used to transmit the degree of conjunction with a nrg global control unit. This control unit converts the resistance value of the level sensor to a proportional analogue signal
Shipping Information
Availability
In Stock
Price
Excluding all taxes
Ships from
Vadodara
Delivery Location
All India delivery available
Shipping
As per delivery location
Seller Information
N
NRG Global Instruments
Verified
Vadodara, Gujarat, India
Established:
2020
Delivery Time:
30–45 Business Days
Shipping Options:
Trust & Safety
Trade Assurance Protected
Secure Payment Methods
Logistics Tracking Available
24/7 Customer Support
