Protection IP 56, Brand Baumer Posital Fraba UTD-IPH00-XXXXX-05M0-2TW, Encoder Type HeavyDuty Incremental Encoder, Color Silver

Flange, 50, S/shaft, 8mm, Clampg, A/r cable, 2m, 1, 16384 ppr mechanical data zinc-plated flange made from sturdy steel housing material type clamp, 50 Aluminum shaft constructed as a solid single flat type, Measuring 15 mm in length and 8 mm in diameter with a shaft material of 0. 31 Constructed from stainless steel grade V2A 1. 4305, Featuring a peak axial shaft load of 40 N, Radial load capacity of 110 N, And rotor inertia measuring 30 gcm (0. 17 oz·in) Friction torque reaches 3 ncm at 20°C, Equivalent to 4. 2 oz. In at 68°F, Allowing for a maximum mechanical speed of 12, 000 revolutions per minute and offering shock resistance Withstand 100 g half sine shocks for 6 ms, According to EN 60068-2-27, And exhibit permanent shock resistance of 10 g half sine for 16 ms, Per EN 60068-2-29 for vibration 10 g of resistance measured at 10 Hz and 1000 Hz, En 60068, 2, 6 length 43 mm 1. 69 weighs 480 g, Equivalent to 1. 06 lbs
