Diameter 4000 mm, Condition New Rubber Vulcanizer, Automation Grade Semi-Automatic, Working Pressure 6 bar

Santosh vulcanisers circular vessels, Are horizontal for curing of rubber articles. These are constructed in diameters ranging from 900mm to 2500mm and the length 1 meter to 12 meters contingent on the necessity of the users. Pressure rating santosh vulcanisers are normally designed and built for a working steam pressure of 5 kg/cm and are tested hydraulically before despatch for a pressure of 7. 5 kg/cm direct / indirect heating for direct steam curing single wall vulcanisers are however for, Standard supply indirect curing coil, In, Chamber type vulcanisers can be supplied with cyclonic, Fan motor for even temp. In vessel. Types of door either swing, Bolt type doors with mono, Rail type sealed against, Retracting mechanism leakage by asbestos ropes or quick, Lock type design presented in picture. Temperature indication & recording instrumentation is capable of being offered for indicating the temperature & also circular chart recorders with mechanical winding arrangement can be provided for recording the temperature. Forced air circulations for hot air curing, Forced air circulation fans can be attached on rear next to the vessel to ensure even temperature at all points in the vulcaniser. These fans are with special water cooled seals. Standard accessories standard vulcanisers are provided alongside blank flanges for steam, Inside batch trolly, Bridge, Stand, Guages etc, Safety valves.
