UsageApplication Laboratory Tissue Processor, Model NameNumber LATP-18

With expert supervision of eminent pathologists our Innovation and research division has developed yet another unique model designed for tissue preparation systems having complete programmer logic controller for complete cycle. Timing & stage sequence, Temperature of the wax bath safety system etc. Are all controlled/operated by delicate touch key board with digital display. The entire unit looks very attractive with aesthetic appeal. The data is retained during a power outage. Front panel comprises digital display, Control switch, Of the key board. The PID-based thermal control unit have been used for controlling the wax bath temperature. Wax bath safety control wax bath pid temperature controller gives signal if temperature is not between 50 to 65 c. Safety system will function at 10th, 11th & 12th position and will stop the main unit in stage 9 onward till the set temperature is attained in the wax bath. Spare accessories automatic wax bath tailored specifically for pid control and pt 100 sensor. It signal s the machine in stage 9, Prior to immersion in wax and if wax is melted it automatically takes change from stage 9 to 10 and so on, But if wax is not melted due to some reasons, Then machine signals wax not melted or temperature is not proper . When wax is melted/wax temperature is attained then only the tissue holder is allowed to immerse or rotate in the wax bath. Thus 100% safety of precious tissue. Basket rotor which rotate the tissue basket slowly. Tissue capsule basket of s. S. With even perforation. Tissue capsule s. S. 28 28 9mm with sliding cover tissue capsule s. S. 20 20 10mm with sliding cover. Tissue capsule s. S. Circular, 36mm dia with auto press lid. Divider for tissue capsule s shape. Divider for tissue capsule v shape. Beaker without lip. This device is offered in a complete package including 2 nos. S. S. Basket rotors, 2 nos. S. S. Baskets, 24 nos. S. S. Tissue capsules, 10 nos. S. S. Beakers without lip, 2 nos. S. S. Wax baths special designed for use with pid temperature controller . Suitable to engage in 220 v, Single-phase, 50Hz hz, Ac supply. Capacity 1 litre, 2 liters
