Brand PECON TR 7576 Six Channel Temp Scanner with 4 To2 0 Ma Remote Output Transformer Protection Relay, Display Type Digital, UsageApplication Industrial

Item specifications We present unused item, A brand-new that is undamaged and fully functional as intended. It is reinforced by a one-year warranty from the manufacturer for any service and repair needs or alternative. This set features a temperature scanner, A test report, And a user manual with detailed technical information descriptions six channel temperature monitor, With a specified range for temperature readings 50 to 250 c. Four signals for errors and fan performance high alarm & exceptionally lofty adventure An autonomous configuration of parameters for 4th channel. Fan exerciser function. 4, 20ma output designed for remote use temperature indication /aux. Deliver 85, 270 vac/dc, With optional choices of 20 and 50 vac/dc . Standard features single scanner unit to measure six temperatures. Four output relays for alarm high, Trip v. High, Fan & fault to warn against sensor open or short circuit condition of sensor connection . Auto fan exerciser memorizes max. Temperature even after power fail conditions. Tr, 7576, Includes analog output 4, 20ma for remote indication, The model tr, 7576 is intended for safe operation within the medium voltage range cast resin / dry type transformer. It works well for control room together with marshalling box installations and is built for long and trouble, Free operation under extreme conditions of service associated with transformer. Three numbers of user settable set, Points can serve as to regulate the cooling fan, To warn the user of high temperature and to shut down the transformer should there be a need for excessive heating. Six nos. Of pt, 100 rtd sensors allow enables the consumer to monitor the temperatures of six windings located suitably in transformer. Tr, 7576 has one analog output signal 4, 20ma . This can be tailored to your specifications to represent the thermal reading of the entirety of the six channels or the heat level of the hottest channel.
