Vacuum Impregnation System, Working pressure 008 MPa -36 MPa, Working temperature 45 - 65 Degree C

Hindhivac vacuum impregnation systems are tailored to impregnate electrical winding of transformers, Waters & coils of various other electrical items for improving their insulation value and their quality. The vacuum impregnation systems have an impregnation chamber which has a vacuum sealed vessel Composed of soft substances steel equipped with a built-in diameter of 500 mm and depth of 650 mm with both top and bottom as dished ends. The top dished end is detachable for loading and unloading of the components meant for impregnation. This air has a, Admittance valve viewing window, Vacuum dial gauges and a light port. The top lid can be moved in and swiveled out aided by the resources of of a davit, Arm. The chamber is jacketed filled with oil and inserted with oil immersion heaters of 1 kw each and are immersed in the oil for heating. Glass wool insulation for the oil heating chamber and cladding constructed using sheet metal to minimize heat loss. The impregnate tank in the vacuum impregnation the setup is additionally a mild steel fabricated chamber and is housed below the main chamber and is linked with the impregnation chamber with a vacuum tight pipeline. In another type impregnation tank is kept to the edge of the impregnation storage chamber and connected each other through a vacuum tight pipe line. The phosphor bronze ball valve with a corrosion-resistant metal ball and teflon seat is utilized for connecting both the vessel and for driving impregnate into the impregnation chamber. An expertly crafted The command module is positioned at the front panel of the structure where the main chamber is situated. . The frame designed and fabricated with angular iron structure provides ample space to accommodate accessories and gives large elbow room for easy service and maintenance. This plant is assured to provide a vacuum of 0. 01m. Bar or better under clean empty and thoroughly degassed chamber conditions.
